6,000 lb DBP

NEWAGE have developed two axles which are suitable for 6,000 lb Draw Bar Pull applications. Utilising the same gearing, NEWAGE are able to offer an 'over the shoulder' & direct input configurations to suit a variety of installations.

NEWAGE 512

The NEWAGE 512 is a triple reduction axle, including an inboard planetary set, that has been developed to withstand the demanding requirements of the ground support Industry.

The 512 is NEWAGE's 'over the shoulder' 6,000 lb DBP axle and it has been designed to retrofit into current axle installations. The 512 is available with a 19.9:1, 15.8:1 12.3:1 or 9.7:1 reduction as standard, and has a universal mounting pad to allow for both solid and spring mount installations. The standard mounting centres are 30.11in (765mm), however the axle can be tailored to suit custom installations. For more information, please click here

NEWAGE 515

The NEWAGE 515 is a double reduction axle, including an inboard planetary set, and offers a 6,000lb DBP direct input solution to NEWAGE's ground support equipment range.

The 515 is available in a variety of ratios, including: 18.6: 1, 15.8:1, 14.8:1, 12.3:1 and 9:1. The 515 uses the same arm as the 512, and so offers a universal mounting pad to allow for both solid and spring mount installations. The standard mounting centres are 27.15in (689.5mm), however the axle can be tailored to suit custom installations. For more information, please click here
